— Smart Touch Screen, Automatic Calculation, Data Exportable
Kinematic viscosity is one of the most important fluid properties of petroleum products, directly affecting oil transport, lubrication and atomization performance. The DFYF‑108B Petroleum Products Kinematic Viscosity Tester is strictly designed in accordance with GB/T 265 and ASTM D445 standards. Featuring a large touch screen and an intelligent timing & calculation system, it upgrades traditional viscosity testing into an efficient, accurate and traceable digital process.
Core Advantages
✅ Dual‑Standard Compliance – Globally Accepted
Complies with GB/T 265 and ASTM D445, suitable for determining the kinematic viscosity of various lubricating oils, fuel oils, crude oils and chemical liquids. Results are recognized worldwide.
✅ 5‑inch True Color Touch Screen – Easy Operation Like a Smartphone
Original imported high‑brightness LCD with an intuitive touch interface. Parameter setting, start timing and result reading are all straightforward – no complex buttons, greatly reducing the learning curve.
✅ Automatic Timing & Automatic Calculation – No More Stopwatches or Manual Math
Tap “Start” and the instrument automatically begins timing. When the test is finished, tap “End” and the system automatically calculates the kinematic viscosity value and saves it to the history log. This eliminates human error and improves efficiency.
✅ Data Exportable to USB Drive – Easy Management & Traceability
Standard USB port allows test data to be saved directly to a USB flash drive for archiving, analysis or report generation on a PC, meeting ISO/CNAS requirements for data traceability.
✅ Four Independent Test Holes – Higher Throughput
Four test positions allow simultaneous testing of multiple samples or parallel samples – ideal for batch testing, saving time.
✅ Transparent Bath + Flow Straightener – Uniform Temperature Field & Clear Observation
Transparent glass bath + acrylic insulation cover: maintains temperature while providing clear visibility of the capillary viscometer.
Built‑in flow straightener ensures smooth bath fluid circulation and uniform temperature distribution across all test holes.
✅ High‑Precision Temperature Control
Temperature range: ambient ~ 100°C, control accuracy: ±0.1°C, meeting viscosity measurement requirements at different temperatures.
Technical Specifications at a Glance
| Parameter | Value |
|---|---|
| Power Supply | AC220V, 50Hz |
| Heating Power | 1500 W |
| Temperature Range | Ambient ~ 100°C |
| Temperature Accuracy | ±0.1°C |
| Number of Test Holes | 4 |
| Applicable Standards | GB/T 265, ASTM D445 |
| Display | 5‑inch true color TFT touch screen |
| Data Interface | USB export |
Target Customers
QC laboratories of petrochemical enterprises and lubricant manufacturers
Third‑party testing laboratories and oil monitoring centers
Oil monitoring departments in power, marine and machinery industries
Petroleum product analysis laboratories in universities and research institutes
Why Choose DFYF‑108B?
✔ Smart & efficient – Automatic timing, automatic calculation, automatic saving – greatly reduces manual work and calculation errors.
✔ Traceable data – USB export function makes it easy to generate test reports, meeting modern laboratory management requirements.
✔ Four independent test holes – Increases throughput, especially suitable for batch QC testing.
✔ Uniform temperature field – Flow straightener + transparent bath design ensures stable temperature and visible testing process.
✔ Robust construction – Compact design suitable for long‑term continuous operation.
Contact Us Today
Let DFYF‑108B help you achieve an intelligent upgrade for kinematic viscosity testing.
📧 For detailed quotations, technical documentation and operation demo videos, please contact us:
📧 Sales email: [lovecarlos2000@gmail.com]
📞 24‑hour hotline: [8615941156556]
— Smart touch screen, automatic calculation, data export – redefining kinematic viscosity testing
