One click start – fully automatic temperature control, testing, cleaning, and drying. Temperature accuracy: ±0.01°C
Pain Points of Traditional Viscosity Testing
Manual timing leads to large errors, cleaning is tedious, temperature control is unstable, and data management is inconvenient – these issues not only reduce laboratory efficiency but also compromise result reliability.
DFYF-108Z Fully Automatic Solution
The instrument features a 10 inch color touchscreen for intuitive operation. With a single press of the start button, it automatically completes the entire process: constant temperature control (with adjustable pre heat time) → automatic sample lifting to the upper level → precise timing by infrared photoelectric sensor → viscosity calculation → storage of up to 1000 data sets → result printing → automatic cleaning and hot air drying. No manual intervention is required – true “set and forget” operation.
Core Advantages Compared with Similar Products
Feature | DFYF-108Z (Our Advantage) | Most Competitors |
Temperature Accuracy | ±0.01°C with Pt100 platinum resistance sensor; over temperature auto power off protection | ±0.05~0.1°C, no safety protection |
Automation | Fully automatic: temperature control, testing, calculation, cleaning, drying | Semi automatic; requires manual cleaning and drying |
Detection Method | High precision infrared photoelectric sensor, accurate timing | Ordinary optical sensor or manual stopwatch |
User Interface | 10 inch color LCD touchscreen | Small monochrome screen or push buttons |
Data Storage | 1000 sets; customizable test, cleaning, and drying cycles; automatic averaging | Limited storage, no customizable cycles |
Material & Illumination | Stainless steel stirrer shaft and viscometer tube holder; energy saving lamp in the bath for clear observation | Rust prone parts, poor illumination |
Test Holes | 2 holes per single bath – compact and efficient | 1 hole per bath or bulky 4 hole design |
Technical Specifications
Parameter | Value |
Temperature Range | Ambient ~100°C |
Temperature Accuracy | ±0.01°C |
Power Supply | AC220V, 50Hz |
Power Consumption | 1200W |
Data Storage | 1000 sets |
Test Holes | 2 per bath |
Ambient Conditions | 10~35°C, ≤85% RH |
Typical Applications
Petroleum and lubricant analysis
In service oil condition monitoring
Industrial oil quality control
R&D for fuels, polymers, and chemicals
Why Choose Dalian Analytical Instrument Factory
Decades of professional manufacturing experience
OEM/ODM support
Comprehensive after sales and technical support
