– Precision & Efficiency for Quenching Oil Analysis
Introduction:
Upgrade your quenching oil testing with the DFYF-201 Heat Treatment Oil Cooling Performance Tester, a reliable instrument designed for accurate cooling curve analysis of heat treatment oils. Engineered to meet SH/T 0220 standards, this advanced benchtop unit delivers precise, repeatable results essential for optimizing industrial quenching processes.
Key Technical Specifications:
Parameter | Value |
Power Supply | AC220V, 50Hz |
Heating Power | 1200W |
Lifting Motor | 6W, 30r/min |
Sampling Rate | 250 times/second |
Max Measuring Temperature | 810°C |
Temperature Accuracy | ±2°C |
Outstanding Performance Features:
1. Smart Automation & Probe Control
Motor-driven silver probe (99.99% purity, integrally extruded) ensures smooth, automatic entry into the sample cup with a single button press.
Reduces manual error and enhances repeatability.
2. Precise Positioning for Consistent Results
A stainless steel ring at the bottom of the test cup guarantees that the probe always reaches the exact center of the oil sample, eliminating deviations caused by uneven temperature distribution.
3. Intelligent Temperature Management
Latest-generation digital temperature controller with intuitive interface for easy, accurate heating control.
4. PC Integration & Data Analysis
Supplied software CD allows full computer control via a separate (customer-supplied) PC.
Real-time temperature vs. time curves displayed on screen; one graph can overlay up to 8 individual cooling curves for side-by-side comparisons.
Automatically calculates:
Characteristic temperature
Cooling time at 400°C
Cooling time at 300°C
Maximum cooling rate
5. Automated Reporting
The system processes, analyzes, and identifies test results, then prints characteristic curves with clear, high-quality output.
Excellent repeatability and accuracy for confident quality assurance.
Why Choose DFYF-201?
Compliance: Meets SH/T 0220 specifications.
Durability: Corrosion-resistant silver probe and robust stainless steel components.
Efficiency: High-speed sampling (250/sec) captures rapid cooling transitions.
Flexibility: PC-based architecture lets you use your existing computer.
Applications:
Ideal for quenching oil manufacturers, heat treatment facilities, and R&D labs requiring precise cooling curve analysis to optimize oil performance and ensure batch-to-batch consistency.
Order Now – Contact our sales team for a quote or technical consultation!
*Boost your heat treatment quality with the DFYF-201 – where precision meets productivity.*
