*Compliant with GB/T 8019 & ASTM D381 for accurate gum determination*
Gum formation in motor gasoline, aviation fuel, and turbine fuels can lead to fuel system deposits, injector fouling, and engine performance loss. The Colloid Stability Tester (also known as Industrial Colloid Testing Equipment or Colloid Testing Analyzer) is designed and manufactured in strict accordance with GB/T 8019 and ASTM D381 – “Standard Test Method for Existent Gum in Fuels by Jet Evaporation”.
It is suitable for measuring the actual gum content of motor gasoline, aviation gasoline, and aviation turbine fuels during formulation and testing. The instrument can also be used to determine the unwashed gum content of automotive gasoline.
| Parameter | Value |
|---|---|
| Power supply | AC220V ±10%, 50Hz |
| Power | 3500W |
| Temperature control range | Ambient ~ 300°C (any setting) |
| Temperature control accuracy | ±1°C |
| Working pressure of air pressure reducing valve | 0.07 MPa |
| Operating temperature range | 160 ~ 165°C |
| Number of test holes | 3 holes |
| Flow display | Float flow meter |
| Air flow rate at nozzle outlet | 600 mL/second per hole |
Key Features & Advantages✔ Smart touchscreen with industrial-grade processor
The tester features a 5‑inch LCD color screen and an industrial‑grade ARM 32‑bit SMD core processor, offering a user‑friendly interface and smooth operation.
✔ Precision inner tube structure for uniform airflow
A well‑designed inner tube distributes air evenly across three independent channels, controlling the total air flow without the need for per‑channel manual adjustments – greatly simplifying setup.
✔ High‑quality air compressor with stable air source
The built‑in compressor provides a consistent, stable air supply, ensuring reliable and repeatable test conditions.
✔ Wide temperature range with high accuracy (±1°C)
Controllable from room temperature up to 300°C, with a standard operating range of 160–165°C for gum testing – precise enough for demanding fuel analysis.
✔ Three independent test stations
Three holes allow simultaneous testing of multiple samples or replicates, increasing laboratory throughput.
✔ Direct readout of air flow
Each nozzle outlet delivers a fixed airflow of 600 mL/second (displayed via float flow meters), meeting the standard’s requirements without guesswork.
Existent gum determination for motor gasoline, aviation gasoline, and aviation turbine fuels
Unwashed gum testing of automotive gasoline
Fuel quality control for refineries, blending facilities, and inspection labs
R&D of fuel formulations with low gum‑forming tendencies
Third‑party inspection and arbitration analysis per GB/T 8019 / ASTM D381
Ideal for:
Petrochemical testing centers, fuel production plants, aviation fuel suppliers, and independent laboratories.
| Feature | Benefit |
|---|---|
| Compliant with GB/T 8019 & ASTM D381 | Globally recognized methods – trusted results |
| 5‑inch LCD + ARM 32‑bit processor | Easy operation, fast response |
| Precision inner tube with 3‑channel uniform airflow | No individual channel adjustment – saves time |
| Built‑in high‑quality air compressor | Stable, maintenance‑friendly air source |
| Wide temperature range (ambient~300°C), ±1°C accuracy | Precise control for diverse fuels |
| 3 independent test positions | Higher efficiency, parallel testing |
Customization & SupportWe understand that laboratory needs vary. Our company offers customized services for the Colloid Stability Tester, allowing us to meet diverse customer requirements – whether you are a large testing hub or a small quality control lab. We provide suitable solutions and configurations tailored to your specific testing needs.
We continuously invest in R&D of colloid testing analyzers to stay at the forefront of technology, ensuring you receive the most accurate and reliable test results.
Our company has always adhered to a high level of attention and strict control over the quality of our measuring instruments. We fully recognize that product quality directly impacts customer satisfaction and company reputation.
We operate a rigorous quality control process:
Raw material procurement
Manufacturing and assembly
Final product inspection and delivery
Every step is carefully monitored and tested to ensure our products meet the highest standards at every stage.
Get accurate, reliable, and standard‑compliant gum testing for your fuels.
📧 Sales email: [lovecarlos2000@gmail.com]
📞 24‑hour hotline: [+86 15941156556]
Colloid Stability Tester – Intelligent, precise, and built for fuel labs.
