Lubricating Oil & Grease Wear Resistance Tester (Four-Ball Method)

Brand: DFYF
Product origin: Dalian, Liaoning
Delivery time: 1 month
Supply capacity: 200pcs/month

1. The Lubricating Oil Wear Resistance Tester is equipped with a timer, which can automatically stop the spindle motor at the end of the experiment. 2. The Lubricating Oil Wear Resistance Tester has a reasonable structural design and is easy to load and unload. 3. The Lubricating Oil Wear Resistance Tester has high spindle rotation accuracy, small wear mark error, and wear mark measurement is convenient and fast.

Email Annex

Manufactured by Dalian Analytical Instrument Factory

Introduction

The DFYF-907 Lubricant and Grease Anti-Wear Tester (Four‑Ball Method) is designed and manufactured in accordance with GB/T 3142, SH/T 0189, SH/T 0202 and SH/T 0204 standards.It is used to evaluate the load‑carrying capacity and anti‑wear performance of lubricating oils and greases under point‑contact sliding friction conditions, and to determine key indicators including oil film strength (P₈), weld load (P_D), comprehensive wear value (Z_MZ), as well as long‑term wear characteristics.The instrument can also analyze the influence of temperature on lubrication performance and the temperature characteristics of lubricants. Lubricating oil wear resistance tester

Technical Specifications

Parameter	Specification
Power Supply	AC 380 V, 50 Hz
Total Power	1.5 kW
Spindle Speed	1000 r/min ~ 2800 r/min ±40 r/min, continuously adjustable
Temperature Control Range	Ambient temperature ~ 200 °C
Loading Mode	Lever‑type, manual loading
Oil Sample Heating	Rod‑type heater
Axial Test Force	60 N ~ 8 kN
Standard Steel Ball	Φ12.7 mm
Test Force Accuracy	±1%
Wear Scar Measurement	Equipped with a dedicated measuring microscope
Test Time Range	1 s ~ 99 h 99 min

Key Performance Advantages

Multi‑Standard CompatibilityFully compliant with GB/T 3142, SH/T 0189, SH/T 0202 and SH/T 0204, enabling complete evaluation of load‑carrying capacity, anti‑wear performance and extreme‑pressure properties of lubricating oils and greases.
Precision Mechanical StructureThe tester features a rigid frame, high‑precision rotating spindle, lever loading system, temperature control and display unit, and wear‑scar measuring system. All components are precisely matched to ensure stable performance and easy operation.
High‑Precision Test PerformanceThe high‑accuracy spindle effectively reduces measurement deviation. The equipped dedicated microscope allows clear and rapid observation of wear scars, ensuring high repeatability and reliability of test results.
Comprehensive Performance EvaluationUsing four standard 12.7 mm steel balls under point‑contact sliding friction, the instrument measures P₈ (oil film strength), P_D (weld load), Z_MZ (comprehensive wear value) and long‑term wear. It also supports evaluation of temperature effects on lubrication performance and thermal characteristics.

Typical Applications

Lubricant & grease manufacturers for quality control and R&D of anti‑wear & extreme‑pressure additives
Automotive and industrial machinery OEMs for lubricant performance verification
Third‑party testing laboratories and commodity inspection authorities
Research institutes engaged in tribology and lubrication technology research

Why Choose DFYF-907?

✅ Full Standard ComplianceMeets multiple national and industrial standards, satisfying regulatory requirements for lubricant performance evaluation.

✅ Stable & Repeatable ResultsHigh‑precision spindle, ±1% test force accuracy and dedicated wear‑scar microscope ensure consistent and traceable test data.

✅ Versatile Testing FunctionsCapable of testing both load‑carrying and anti‑wear properties. Adjustable speed, load and temperature allow simulation of various working conditions.

✅ Stable Structure & Easy OperationCompact and modular design with user‑friendly controls and low maintenance, ideal for daily quality control and research applications.
